OMRON - Composants de sécurité - Safety Light Curtain/Safety Multi-Light Beam - F3SG-4PGA0670-2C

Easy to monitor and ready for IoT

Sensing method: Safety multi-beam
Type of protection: Body protection
Number of beams: 2
Safety field height: 670 mm
Type of safety according to IEC 61496-1: 4
Beam spacing: 500 mm
Maximum safety range: 5 m
Minimum operating distance: 0.5 m
Key features: Active/passive, Area Beam Indicator, Auxiliary output, Designated beam output, External Device Monitoring (EDM), External test, Interlock, Muting, Mutual interference prevention, PNP/NPN selection, Response time adjustment
Degree of protection (IP): IP65/IP67
Cascadable: FALSE
Number of protected semiconductor outputs: 2
Number of semiconductor outputs with signalling function: 1
Type of switching output of the OSSD: PNP/NPN
Response time: 8 ms
With muting function: TRUE
With beam coding: TRUE
Communication option(s): Bluetooth, IO-Link, USB
Scope of delivery: Transmitter and receiver
Wavelength of the sensor: 870 nm
Connection method: Root connector (order separately)
Max. output current at protected output: 300 mA
Ambient temperature: -30-55 °C
Number of fixed side-mount brackets: 2
Number of adjustable side-mount brackets: 2
Number of intermediate brackets: 0

• Conforms to major international standards

• Environmental resistance and rugged structure for use in various environments (IP67, IP67G*1, IP69K*2)

• A broad line-up, from finger protection to body protection

• Flexible height model for easy integration into machines and lines

• IoT ready via IO-Link *1. IEC 60529/JIS C 0920 Annex 1 *2. Available with the F3SG-SR-K IP69K Model
