EGE Elektronik - Détecteurs de proximité - Z01214 - KBM 030 B-A2
Reference : KBM 030 B-A2
Marque : EGE Elektronik
Prix unitaire
- Prix HT
173,79 €
Prix TTC208,55 € - QuantitéPrix unitaire HT3168,576€5165,1€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
Z01214-KBM 030 B-A2 Impact- and shock resistant, protected installation of indictive sensors
| Product ID | Z01214 |
| Description | mounting clamp for metal face sensors |
| For sensors threaded: | M30 |
| Dimensions L1xL2xL3 | 55x40x40 |
| Sensor installation | set back (see drawing) |
| Note | Mounting clambs are fastened to their metal surface using M6 hexagon socket screws. Make sure that the proivided stainless steel washers have been placed in-between. The typical torque is 6 Nm. |
| Material | stainless steel AISI 303 |
| Hole spacing e | 40 mm |
| TYPE | KBM 030 B-A2 |
