EGE Elektronik - Contrôleurs de débit - P11331 - SDN 503/1 GA
Livraison gratuite
Reference : SDN 503/1 GA
Marque : EGE Elektronik
Prix unitaire
- Prix HT
762,76 €
Prix TTC915,31 € - QuantitéPrix unitaire HT3739,877€5724,622€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P11331-SDN 503/1 GA Flow rate sensor with amplifier Robust, compact housing from glass fibre reinforced PBT
| Product ID | P11331 |
| Accessories (in scope of delivery) | 4 x gasket G1/4 AFM 34, Screwdriver |
| Protection [EN 60529] | IP 67 |
| Material housing | PBT |
| Compressive strength | 10 bar |
| Sensor length L | 68 mm |
| Inner diameter d | 3.6 mm |
| Medium temperature | 0 ... 60 °C |
| Current consumption max. | 50 mA |
| Electrical connection | M12 connector |
| Supply voltage | 24 VDC +/- 10 % |
| Material sensor touched by medium | stainless steel AISI 316 Ti |
| Accessories | connecting cable SLG, SLW, SBG, SBW, mounting bracket |
| Reverse polarity protection | ✓ |
| Reaction time typ. | 0.5 ... 10 s |
| Detection range ml/min | 0.1 ... 500 ml/min |
| Working range | 1 ... 200 ml/min |
| Ambient temperature | 0 ... 60 °C |
| Medium | Water |
| Process connection | G1/4 |
| Output | analog output 4…20 mA, non linear |
| Start-up time typ. | 5 ... 60 s |
| Load RL | 200 ... 500 Ω |
| TYPE | SDN 503/1 GA |
