OMRON - Automates programmables - Automates programmables CP1 - CP1E-E10DR-D
Reference : CP1E-E10DR-D
Marque : OMRON
Prix unitaire
- Prix HT
206,43 €
Prix TTC247,71 € - QuantitéPrix unitaire HT3200,233€5196,105€
-
Quantité minimale : 1
-
Quantité :
-
Description
Api pour 10 e/s de base (pas d'ext.), 1 x usb. 1,1 ms/k instructions de base. 2k pas programme et 2k mots de données. 6 entrées (4 interruptives (10 khz) / 2 compteurs 10 khz). 4 sorties relais 2 a. tension 24 vc.c.
| Built-in auxiliary 24 VDC output | 0 mA |
| Communication option(s) | None |
| Real-time clock | |
| Analog option boards | |
| Max. number of analog I/O channels | 0 |
| Number of Ethernet ports | 0 |
| Program capacity | 2 K steps |
| Depth | 85 mm |
| Supply voltage type | DC |
| Number of RS-485 ports | 0 |
| Max. encoder input frequency | 10 kHz |
| Number of RS-232 ports | 0 |
| Max. pulse output frequency | 0 kHz |
| Communication port(s) | USB |
| Output type | Relay |
| Battery-free memory backup | |
| Height | 90 mm |
| Width | 66 mm |
| Operating temperature range | 0-55 °C |
| Max. number of expansion units | 0 |
| Product Weight (unpacked) | 300 g |
| Data memory capacity | 2 K words |
| Max. number of local I/O points | 10 |
| Input type | PNP/NPN |
| Number of digital outputs | 4 |
| Logic execution time | 1.19 µs |
| Function Block programming | |
| Number of USB ports | 1 |
| Max. number of PTP axes | 0 |
| Number of digital inputs | 6 |
