OMRON - Relais industriels et pour circuits imprimés - Relais Statiques G3PB - G3PE-215B 12-24VDC
Reference : G3PE-215B 12-24VDC
Marque : OMRON
Prix unitaire
- Prix HT
61,04 €
Prix TTC73,25 € -
Quantité minimale : 1
-
Quantité :
-
Description
Ssr 1 phase, avec radiateur, indicateur deel, capot de protection, avec fonction de coupure au zéro de tension, promaire 12-24 vc.c., 15 a, secondaire 75-264 vc.a., montage rail din ou à visser
| Minimum operating temperature | -30 °C |
| Complete with socket | |
| Supply voltage DC | 12-24 V |
| Rated operational voltage, AC | 100-240 V |
| Control current max. | 10 mA |
| Terminal | Screw |
| Applicable heater capacity (AC1: resistive load) | 3 kW |
| Depth | 100 mm |
| Rated operation current Ie at AC-1 | 15 A |
| Maximum operating temperature | 80 °C |
| Switching at zero-crossing | |
| Number of phases | 1 |
| Must release voltage min. | 1 V |
| Mounting method | DIN rail/screw |
| Permissible I²t value | 121 A²s |
| With LED indicator | |
| Isolation | Phototriac |
| Height | 100 mm |
| Must operate voltage max. | 9.6 V |
| Application | ON/OFF control |
| Operating voltage range, AC | 75-264 V |
| Width | 22.5 mm |
| Number of poles | 1 |
