EGE Elektronik - Détecteurs de proximité - P31255 - IGMU 15 GSOP
Reference : IGMU 15 GSOP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
115,98 €
Prix TTC139,18 € - QuantitéPrix unitaire HT3112,501€5110,181€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P31255-IGMU 15 GSOP Inductive proximity switches resistant against electromagnetic interference which might arise from cables or radiation. For use in systems with challenging EMC conditions Customer-specific adaptations For the detection of metallic objects, presence detection, Position and movement monitoring, Object counting and Speed control on conveyor belts
| Material cap | PBT |
| Product ID | P31255 |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 2 V |
| Material housing | brass-Ni, PBT |
| Material thread | Br-Ni |
| Thread/sleeve | M30x1,5 |
| Current consumption max. | 2.5 mA |
| Short circuit proof | yes |
| Electrical connection | M12 connector |
| Operating Distance sn | 15 mm non-flush |
| Supply voltage | 10...48 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 500 Hz |
| Ambient temperature | -25 ... 75 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGMU 15 GSOP |
| Display | ✓ |
