EGE Elektronik - Contrôleurs de débit - P11294 - SDN 552/2 GPP
Livraison gratuite
Reference : SDN 552/2 GPP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
730,17 €
Prix TTC876,20 € - QuantitéPrix unitaire HT3708,265€5693,661€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P11294-SDN 552/2 GPP 7-segment flow rate and temperature display 2 x switching output PNP NC / NO contact Detection range: 2...20 l/min Flow and temperature monitoring of water and water-glycol mixtures
| Product ID | P11294 |
| Outer Diameter Pipe mm | 15 mm |
| Output function | PNP-NO / NC |
| Detection range water/glycol | 2 ... 20 l/min |
| Protection [EN 60529] | IP 65 |
| Material housing | PBT |
| Compressive strength | 20 bar |
| Temperature monitoring | -10 ... 90 °C |
| Medium temperature | -10 ... 90 °C |
| Current consumption max. | 100 mA |
| Electrical connection | M12 connector |
| Detection range water | 2 ... 20 l/min |
| Supply voltage | 24 VDC +/- 10 % |
| Material sensor touched by medium | FPM, stainless steel AISI 316 Ti |
| Accessories | mounting plate, adapter SDA G1/4-Ø-10-L050 (Z01175), adapter SDA G1/2-Ø-18-L068 (Z01176) |
| Reverse polarity protection | ✓ |
| Reaction time typ. | 1 ... 8 s |
| Ambient temperature | 0 ... 80 °C |
| Medium | Water, water/glycol |
| Process connection | tube fittings for steel tubes accord. to ISO 3304 / DIN 2391 |
| Output | 2 x switching output |
| Programmable functions | time on/off delay, switch on delay, two switching points, averaging, access code, hysteresis, switching point, adjustable to reference, glycol percentage, NC/NO |
| TYPE | SDN 552/2 GPP |
| Display | 7-segment / 3 digits |
