EGE Elektronik - Contrôleurs de débit - P11275 - SDN 506 GR-CER
Livraison gratuite
Reference : SDN 506 GR-CER
Marque : EGE Elektronik
Prix unitaire
- Prix HT
661,38 €
Prix TTC793,66 € - QuantitéPrix unitaire HT3641,539€5628,311€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P11275-SDN 506 GR-CER Flow rate sensor with amplifier Robust housing from glass fibre reinforced PBT Ceramic measuring cell, metal free in contact with media Relay output Detection range 0,005...3 l/min
| Product ID | P11275 |
| Accessories (in scope of delivery) | screwdriver |
| Protection [EN 60529] | IP 67 |
| Material housing | PBT |
| Compressive strength | 5 bar |
| Medium temperature | 0 ... 60 °C |
| Electrical connection | M12 connector |
| Material sensor touched by medium | AL2O3, FPM, PTFE |
| Accessories | connecting cable SLG, SLW, SBG, SBW |
| Reverse polarity protection | ✓ |
| Temperature gradient fluids | 400 K/min |
| Reaction time typ. | 1 s (5 ... 5 s) |
| Ambient temperature | 0 ... 60 °C |
| Process connection | G1/4 |
| Output | switching output |
| TYPE | SDN 506 GR-CER |
| Switching current max. | 1000 mA |
| Output function | relay |
| Switching voltage max. | 30 VAC / 36 VDC |
| Inner diameter d | 6 mm |
| Current consumption max. | 50 mA |
| Detection range water | 0.005 ... 3 l/min |
| Supply voltage | 24 VDC +/- 10 % |
| Working range | 0.02 ... 3 l/min |
| Medium | Water |
| Start-up time typ. | 5 ... 15 s |
