EGE Elektronik - Contrôleurs de débit - P11300 - LDN 510 GR
Reference : LDN 510 GR
Marque : EGE Elektronik
Prix unitaire
- Prix HT
465.86 €
Prix TTC559.03 € - QuantitéPrix unitaire HT3451.884€5442.567€
-
Quantité minimale : 1
- Quantité :
-
Description
For monitoring of the flow speed of gaseous media in the range of 0,2…60 m/s Wear-free, no moving parts Monitoring of compressed air supllies Without loss of pressure, no constrictions in measuring pipe With relay output
| Product ID | P11300 |
| Accessories (in scope of delivery) | 4 x gasket G1/4 AFM 34, Screwdriver |
| Protection [EN 60529] | IP 67 |
| Material housing | PBT |
| Compressive strength | 20 bar |
| Sensor length L | 68 mm |
| Medium temperature | -20 ... 80 °C |
| Electrical connection | M12 connector |
| Material sensor touched by medium | stainless steel AISI 316 Ti |
| Accessories | connecting cable SLG, SLW, SBG, SBW, mounting bracket |
| Reverse polarity protection | ✓ |
| Reaction time typ. | 1 ... 20 s |
| Ambient temperature | 0 ... 60 °C |
| Process connection | G1/4 |
| Output | switching output |
| TYPE | LDN 510 GR |
| Switching current max. | 1000 mA |
| Output function | relay NO |
| Switching voltage max. | 30 VAC / 36 VDC |
| Detection range air | 0.2 ... 60 m/s |
| Inner diameter d | 9 mm |
| Current consumption max. | 50 mA |
| Supply voltage | 24 VDC +/- 10 % |
| Working range | 0.5 ... 40 m/s |
| Medium | air, non-explosive gas |
| Temperature gradient gaseous media | 20 K/min |
| Start-up time typ. | 10 ... 30 s |
