EGE Elektronik - Contrôleurs de débit - P11100 - LTZ 421 K-A2
Reference : LTZ 421 K-A2
Marque : EGE Elektronik
Prix unitaire
- Prix HT
251.03 €
Prix TTC301.24 € - QuantitéPrix unitaire HT3243.499€5238.478€
-
Quantité minimale : 1
- Quantité :
-
Description
Screw-in sensors series LTZ 400 for flow monitoring Gaseous media Robust Stainless steel housing G1/2 threads for assemble in T-piece or welding sleeve Flow monitoring in supply and exhaust air ducts Flow monitoring in exhaust systems
| Product ID | P11100 |
| Accessories (in scope of delivery) | 2 x gasket G1/2 AFM 34 |
| Associated amplifiers | SKM 421 GR, SKM 421 GSP, SKM 420 GA, SKM 522 GR, SKM 522 WR, SKZ 400 GR, SKZ 400 WR-115, SKZ 400 WR |
| Protection [EN 60529] | IP 68 |
| Material housing | stainless steel AISI 303, brass |
| Compressive strength | 30 bar |
| Sensor length L | 48 mm |
| Detection range air | 0.5 ... 30 m/s |
| Medium temperature | -20 ... 80 °C |
| Electrical connection | 2 m PVC-cable 4x0.25 mm² |
| Material sensor touched by medium | stainless steel AISI 303 |
| Ambient temperature | -20 ... 80 °C |
| Medium | air, non-explosive gas |
| Process connection | G1/2 |
| Temperature gradient gaseous media | 20 K/min |
| Note | probe with longer cable available on request |
| Reaction time | 2 ... 30 s |
| Start-up time | 10 ... 90 s |
| TYPE | LTZ 421 K-A2 |
