OMRON - Automates programmables - Automates programmables CP1 - CP1E-N14DR-A
Reference : CP1E-N14DR-A
Marque : OMRON
Prix unitaire
- Prix HT
297,18 €
Prix TTC356,61 € - QuantitéPrix unitaire HT3288,261€5282,317€
-
Quantité minimale : 1
-
Quantité :
-
Description
Api pour 14 e/s de base (pas d'ext.), 1 x usb. 1,1 ms/k instructions de base. 8k pas programme et 8k mots de données. 8 entrées (6 interruptives (10 khz) / 1 compteur 100 khz, 1 compteur 10 khz). 6 sorties relais 2 a. tension 240 vc.a.
| Built-in auxiliary 24 VDC output | 0 mA |
| Communication option(s) | None |
| Real-time clock | |
| Analog option boards | |
| Max. number of analog I/O channels | 0 |
| Number of Ethernet ports | 0 |
| Program capacity | 8 K steps |
| Depth | 85 mm |
| Supply voltage type | AC |
| Number of RS-485 ports | 0 |
| Max. encoder input frequency | 100 kHz |
| Number of RS-232 ports | 1 |
| Max. pulse output frequency | 0 kHz |
| Communication port(s) | Serial RS-232C, USB |
| Output type | Relay |
| Battery-free memory backup | |
| Height | 90 mm |
| Width | 86 mm |
| Operating temperature range | 0-55 °C |
| Max. number of expansion units | 0 |
| Product Weight (unpacked) | 360 g |
| Data memory capacity | 8 K words |
| Max. number of local I/O points | 14 |
| Input type | PNP/NPN |
| Number of digital outputs | 6 |
| Logic execution time | 1.19 µs |
| Function Block programming | |
| Number of USB ports | 1 |
| Max. number of PTP axes | 0 |
| Number of digital inputs | 8 |
