EGE Elektronik - Détecteurs de proximité - P31456 - IGFW 015 GOP
Reference : IGFW 015 GOP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
187,07 €
Prix TTC224,48 € - QuantitéPrix unitaire HT3181,458€5177,716€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P31456-IGFW 015 GOP For use in wet and warm processes and aggressive fluids Resistant to roller oil For use at temperatures up to 120°C Climatic proofed For use in environments with heavily seeping oil For use in the steel industry
| Material cap | PTFE |
| Product ID | P31456 |
| Output function | PNP-NC |
| Overcurrent release | 230 mA |
| Protection [EN 60529] | IP 68 + IP 69K |
| Voltage drop max. | 2 V |
| Material housing | PTFE |
| Material thread | PTFE |
| Residual ripple | 10 % |
| Thread/sleeve | M30x1,5 |
| Current consumption max. | 4 mA |
| Operating Distance sn | 10 mm flush |
| Temperature deviation (25...70°C) | 10 % |
| Supply voltage | 10 ... 30 VDC |
| Reverse polarity protection | ✓ |
| Temperature deviation (25...120°C) | 20 % |
| Switching frequency | 1000 Hz |
| Ambient temperature | -25 ... 120 °C |
| EMC-class | A |
| TYPE | IGFW 015 GOP |
