EGE Elektronik - Détecteurs de proximité - P31013 - IGM 1 GSP
Reference : IGM 1 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
88.47 €
Prix TTC106.16 € -
Quantité minimale : 1
- Quantité :
-
Description
Inductive proximity switches resistant against electromagnetic interference which might arise from cables or radiation. For use in systems with challenging EMC conditions Customer-specific adaptations For the detection of metallic objects, presence detection, Position and movement monitoring, Object counting and Speed control on conveyor belts
| Material cap | stainless steel AISI 316 Ti (A4) |
| Product ID | P31013 |
| Output function | PNP-NO |
| Overcurrent release | 250 mA |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 2 V |
| Material housing | stainless steel AISI 316 Ti, stainless steel |
| Material thread | stainless steel AISI 316 Ti (A4) |
| Thread/sleeve | M8x1 |
| Current consumption max. | 10 mA |
| Short circuit proof | yes |
| Operating Distance sn | 15 mm flush |
| Supply voltage | 10...30 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 1000 Hz |
| Ambient temperature | -25 ... 70 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGM 1 GSP |
| Display | ✓ |
