EGE Elektronik - Détecteurs de proximité - P31339 - IGMW 04 GSP
Reference : IGMW 04 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
187.07 €
Prix TTC224.48 € - QuantitéPrix unitaire HT3181.458€5177.716€
-
Quantité minimale : 1
- Quantité :
-
Description
For use at temperatures up to 120°C Climatic proofed Water-tight and resistant to high pressure cleaning Particularly resistant to steam For use in cleaning processes For use in cooking processes
| Material cap | PTFE |
| Product ID | P31339 |
| Switching current max. | 200 mA |
| Output function | PNP-NO |
| Overcurrent release | 230 mA |
| Protection [EN 60529] | IP 68 + IP 69K |
| Voltage drop max. | 2 V |
| Residual current | 1 |
| Material housing | stainless steel AISI 316 Ti, stainless steel, PTFE |
| Material thread | stainless steel AISI 316 Ti (A4) |
| Residual ripple | 10 % |
| Thread/sleeve | M12x1 |
| Current consumption max. | 4 mA |
| Electrical connection | 2 m FEP-cable 3x0.34 mm² |
| Operating Distance sn | 4 mm non-flush |
| Supply voltage | 10...30 VDC |
| Switching frequency | 1000 Hz |
| Ambient temperature | -25 ... 120 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGMW 04 GSP |
