EGE Elektronik - Détecteurs de proximité - P31228 - IGV 02 GSP
Reference : IGV 02 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
129.14 €
Prix TTC154.97 € - QuantitéPrix unitaire HT3125.266€5122.683€
-
Quantité minimale : 1
- Quantité :
-
Description
One piece from stainless steel Especially resistant to vibration and shocks for use in mobile machines and heavy duty applications
| Material cap | stainless steel AISI 316 L |
| Product ID | P31228 |
| Switching current max. | 250 mA |
| Output function | PNP-NO |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 1.5 V |
| Material housing | stainless steel AISI 316 L, stainless steel |
| Material thread | stainless steel AISI 316 L |
| Thread/sleeve | M12x1 |
| Current consumption max. | 5 mA |
| Short circuit proof | yes |
| Electrical connection | 2 m PVC-cable 3x0.34 mm² |
| Operating Distance sn | 2 mm flush |
| Supply voltage | 10 ... 30 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 180 Hz |
| Ambient temperature | -25 ... 80 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGV 02 GSP |
| Display | ✓ |
