EGE Elektronik - Détecteurs de proximité - P31366 - IGVO 10 GSP
Reference : IGVO 10 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
463.45 €
Prix TTC556.14 € - QuantitéPrix unitaire HT3449.546€5440.277€
-
Quantité minimale : 1
- Quantité :
-
Description
With one-piece stainless steel sleeve for particular resistance to mechanical stress Pressure-resistant up to 300 m water depth With longitudinally watertight anti-leak cable for the reliable continuous use under water For use in offshore plants
| Material cap | stainless steel AISI 316 L |
| Product ID | P31366 |
| Switching current max. | 250 mA |
| Output function | PNP-NO |
| Protection [EN 60529] | IP 68 + IP 69K |
| Material housing | stainless steel AISI 316 L |
| Material thread | stainless steel AISI 316 L |
| Thread/sleeve | M30x1,5 |
| Current consumption max. | 5 mA |
| Short circuit proof | yes |
| Electrical connection | 1 m longitudinal water blocked PLWDC-cable 3x0,5 mm² |
| Operating Distance sn | 10 mm flush |
| Supply voltage | 10 ... 30 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 150 Hz |
| Ambient temperature | -25 ... 70 °C |
| Output | switching output |
| EMC-class | A |
| Seal material | FKM |
| TYPE | IGVO 10 GSP |
