EGE Elektronik - Détecteurs de proximité - P31225 - IGVU 02 GS
Reference : IGVU 02 GS
Marque : EGE Elektronik
Prix unitaire
- Prix HT
116.59 €
Prix TTC139.91 € - QuantitéPrix unitaire HT3113.092€5110.76€
-
Quantité minimale : 1
- Quantité :
-
Description
IGV solid stainless steel sensors For high mechanical stress One piece from stainless steel Especially impact-proof Resistant to vibration and shock For use under harsh mechanical conditions Inductive proximity switches for use in the mobile machinery and Heavy duty applications
| Material cap | stainless steel AISI 316 L |
| Product ID | P31225 |
| Switching current max. | 150 mA |
| Protection [EN 60529] | IP 68 + IP 69K |
| Voltage drop max. | 3.5 V |
| Material housing | stainless steel AISI 316 L, stainless steel |
| Material thread | stainless steel AISI 316 L |
| Thread/sleeve | M12x1 |
| Current consumption max. | 1.5 mA |
| Short circuit proof | yes |
| Electrical connection | M12 connector |
| Operating Distance sn | 2 mm flush |
| Supply voltage | 8 ... 30 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 180 Hz |
| Ambient temperature | -25 ... 80 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGVU 02 GS |
| Display | ✓ |
