EGE Elektronik - Détecteurs de proximité - P31238 - IGVW 05 GSP
Reference : IGVW 05 GSP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
179,83 €
Prix TTC215,80 € - QuantitéPrix unitaire HT3174,435€5170,839€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P31238-IGVW 05 GSP Solid stainless steel sensor Climatic proofed and water-tight Resistant to high pressure cleaning up to 110° C, Protection class IP 68 / IP 69 Resistant to vibration and shock For use in cleaning areas For use during refining processes
| Material cap | stainless steel AISI 316 L |
| Product ID | P31238 |
| Switching current max. | 250 mA |
| Output function | PNP-NO |
| Protection [EN 60529] | IP 68 + IP 69K |
| Voltage drop max. | 1.5 V |
| Material housing | stainless steel AISI 316 L, stainless steel |
| Material thread | stainless steel AISI 316 L |
| Thread/sleeve | M18x1 |
| Current consumption max. | 5 mA |
| Short circuit proof | yes |
| Electrical connection | 2 m FEP-cable 3x0.34 mm² |
| Operating Distance sn | 5 mm flush |
| Supply voltage | 10 ... 30 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 180 Hz |
| Ambient temperature | -10 ... 110 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGVW 05 GSP |
