EGE Elektronik - Détecteurs de proximité - P31452 - IKMb 123 Ex-230
Reference : IKMb 123 Ex-230
Marque : EGE Elektronik
Prix unitaire
- Prix HT
226.90 €
Prix TTC272.28 € - QuantitéPrix unitaire HT3220.093€5215.555€
-
Quantité minimale : 1
- Quantité :
-
Description
For the connection of intrinsically safe sensors For top hat rail mounting in a switch cabinet in a non-explosive area
| Product ID | P31452 |
| Switching current max. | 4 A AC / 0,8 A DC / 4 A DC |
| IECEx marking dust | [Ex ia Da] IIIC |
| Output function | relay / change-over |
| Switching voltage max. | 250 VAC / 60 VDC / 24 VDC |
| Maximum values | Uo = 9.6 V / Io = 50.5 mA / Po = 121.3 mW / Co = 0.68 µF / Lo = 5.00 mH |
| Protection [EN 60529] | IP 20 |
| ATEX Certificate | EPS 17 ATEX 1 091 |
| IECEx Certificate | IECEx EPS 17.0047 |
| ATEX marking gas | Ex II (1) G [Ex ia Ga] IIC |
| Switching Load | cos φ >0,7 / L/R ≤ 200 ms / L/R ≤ 200 ms |
| Electrical connection | terminal screws |
| Supply voltage | 230 VAC +/- 10% |
| ATEX Marking dust | Ex II (1) D [Ex ia Da] IIIC |
| Ambient temperature | -20 ... 60 °C |
| Rated voltage | 253 VAC |
| Output | switching output |
| IECEx marking gas | [Ex ia Ga] IIC |
| Note | area of use: only outside of the hazardous areas (gas or dust) |
| TYPE | IKMb 123 Ex-230 |
| Display | LED Power: green / switching output: yellow / cable break: red |
