EGE Elektronik - Détecteurs de proximité - P30165 - INKS 020 GPP
Reference : INKS 020 GPP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
121.90 €
Prix TTC146.28 € - QuantitéPrix unitaire HT3118.243€5115.805€
-
Quantité minimale : 1
- Quantité :
-
Description
Inductive proximity switches for industry and automation Good value for money Sensors With smooth plastic sleeve Customer-specific adaptations For the detection of metallic objects Presence detection Position and movement monitoring Object counting and Speed control on conveyor belts
| Material cap | PBT |
| Product ID | P30165 |
| Switching current max. | 400 mA |
| Overcurrent release | 450 mA |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 2 V |
| Material housing | PBT |
| Current consumption max. | 2.5 mA |
| Short circuit proof | yes |
| Electrical connection | 2 m PVC-cable 3x0.5 mm² |
| Operating Distance sn | 20 mm non-flush |
| Supply voltage | 10 ... 55 VDC |
| Reverse polarity protection | ✓ |
| Switching frequency | 500 Hz |
| Ambient temperature | -25 ... 75 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | INKS 020 GPP |
| Display | ✓ |
