EGE Elektronik - Temporisation/ Compteurs - P11287 - SDN 520 GA
Livraison gratuite
Reference : SDN 520 GA
Marque : EGE Elektronik
Prix unitaire
- Prix HT
667,41 €
Prix TTC800,89 € - QuantitéPrix unitaire HT3647,388€5634,039€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P11287-SDN 520 GA Flow rate sensor with amplifier Robust, compact housing from glass fibre reinforced PBT
| Product ID | P11287 |
| Accessories (in scope of delivery) | screwdriver |
| Protection [EN 60529] | IP 67 |
| Material housing | PBT |
| Compressive strength | 20 bar |
| Inner diameter d | 19 mm |
| Medium temperature | 0 ... 80 °C |
| Current consumption max. | 50 mA |
| Electrical connection | M12 connector |
| Detection range water | 3 ... 40 l/min |
| Supply voltage | 24 VDC +/- 10 % |
| Material sensor touched by medium | FPM, stainless steel AISI 316 Ti |
| Accessories | connecting cable SLG, SLW, SBG, SBW, mounting bracket |
| Reverse polarity protection | ✓ |
| Temperature gradient fluids | 400 K/min |
| Reaction time typ. | 0.5 ... 10 s |
| Working range | 4 ... 30 l/min |
| Ambient temperature | 0 ... 60 °C |
| Medium | Water |
| Process connection | G3/4 |
| Output | analog output 4…20 mA, non linear |
| Start-up time typ. | 5 ... 15 s |
| Load RL | 200 ... 500 Ω |
| TYPE | SDN 520 GA |
