EGE Elektronik - Détecteurs de proximité - P30015 - IGMS 010 WP
Reference : IGMS 010 WP
Marque : EGE Elektronik
Prix unitaire
- Prix HT
141,21 €
Prix TTC169,45 € - QuantitéPrix unitaire HT3136,974€5134,149€
-
Quantité minimale : 1
-
Quantité :
-
Description
Documentation
P30015-IGMS 010 WP Inductive proximity switches resistant against electromagnetic interference which might arise from cables or radiation. For use in systems with challenging EMC conditions Customer-specific adaptations For the detection of metallic objects, presence detection, Position and movement monitoring, Object counting and Speed control on conveyor belts
| Material cap | PBT |
| Product ID | P30015 |
| Switching current max. | 400 mA |
| Protection [EN 60529] | IP 67 |
| Voltage drop max. | 6 V |
| Minimum load current | 5 mA |
| Material housing | brass-Ni, PBT |
| Material thread | Br-Ni |
| Thread/sleeve | M30x1,5 |
| Current consumption max. | 2.5 mA |
| Electrical connection | 2 m PVC-cable 2x0,5 mm² |
| Operating Distance sn | 10 mm flush |
| Supply voltage | 20...250 VAC |
| Switching frequency | 25 Hz |
| Ambient temperature | -25 ... 75 °C |
| Output | switching output |
| EMC-class | A |
| TYPE | IGMS 010 WP |
| Display | ✓ |
